Input/Output Connector D-SUB Connector HDR
D-SUB Connectors

HDR

2.29mm HIGH DENSITY D-SUB RIGHT ANGLE BLACK INSULATOR
  • HDR

  • 15
    (1)
  • P
    (2)
  •
    H
    (3)

Description

  • (1) 15、26、44、62、78:NO. OF POSITION
  • (2) P:MALE BOARDLOCK WITH 2 JACKSCREW 4#40 INSTALLED
          S:FEMALE BOARDLOCK WITH 2 JACKSCREW 4#40 INSTALLED
          PN:MALE RIVET TYPE WITHOUT FRONT JACKSCREW
          SN:FEMALE RIVET TYPE WITHOUT FRONT JACKSCREW
          PNJ:MALE RIVET TYPE WITH FRONT JACKSCREW
          SNJ:FEMALE RIVET TYPE WITH FRONT JACKSCREW
          PNH:MALE RIVET TYPE ATTACH SEPARATED JACKSCREW
          SNH:FEMALE RIVET TYPE ATTACH SEPARATED JACKSCREW
  • (3) RoHS
  • IMG_2409-2
  • IMG_2408-2
  • IMG_2410-2
  • IMG_2413-2
  • IMG_2412-2
  • IMG_2414-2
INQUIRY
INQUIRY

DOWNLOAD

PART NUMBER SIZE FILE TYPE DRAWINGS
HDRXXPNJ-XX-SXX-H 313KB PDF
download
DOWNLOAD
HDRXXPN-XX-SXX-H 294KB PDF
download
DOWNLOAD
HDRXXSN-XX-SXX-H 297KB PDF
download
DOWNLOAD
HDRXXP-H 292KB PDF
download
DOWNLOAD
HDRXXS-H 291KB PDF
download
DOWNLOAD
HDRXXSNH-XX-H 293KB PDF
download
DOWNLOAD
HDRXXSNJ-XX-SXX-H 301KB PDF
download
DOWNLOAD
