Housing,Header and Terminal

PH

2.0mm PH BOARD TO WIRE
  • PH

  • 15
    (1)
  • H
    (2)
  •
    H
    (3)

Description

  • (1) 02~15:NO. OF POSITION
          T:FEMALE TERMINAL TIN PLATED
  • (2) H:FEMALE HOUSING
          D:MALE DIP STRAIGHT
          R:MALE DIP RIGHT ANGLE
          V:MALE SMT STRAIGHT
          W:MALE SMT RIGHT ANGLE
  • (3) RoHS

DOWNLOAD

PART NUMBER SIZE FILE TYPE DRAWINGS
PHXXD-H 256KB PDF
download
DOWNLOAD
PHXXR-H 257KB PDF
download
DOWNLOAD
PHXXVC-R1K-H 263KB PDF
download
DOWNLOAD
PHXXH-H 263KB PDF
download
DOWNLOAD
PHT-R10K-H 76KB PDF
download
DOWNLOAD
