Board & Wire Connector Pin / Female Header SMCXXXP(S)

BOARD TO BOARD

SMCXXXP(S)

1.27mm SMC MALE WITH POST/FITTING NAIL

SMC
010
(1)
PV068C
(2)
H
(3)

Description

(1) 010、012、016、020~100:NO. OF POSITION0402:4P2C
(2) MATING DIMENSION 8.00mm: PV068C(MALE)+SV062C(FEMALE)
MATING DIMENSION 9.40mm: PW082(MALE)+SV062C(FEMALE)
MATING DIMENSION 9.50mm: PV083C(MALE)+SV062C(FEMALE)
MATING DIMENSION 10.85mm: PV068C(MALE)+SV090C(FEMALE)
MATING DIMENSION 11.10mm: PV099C(MALE)+SV062C(FEMALE)
MATING DIMENSION 11.40mm: PV068C(MALE)+SW096(FEMALE)
MATING DIMENSION 12.20mm: PW082(MALE)+SV090C(FEMALE)
MATING DIMENSION 12.30mm: PV083C(MALE)+SV090C(FEMALE)
MATING DIMENSION 12.80mm: PW082(MALE)+SW096(FEMALE)
MATING DIMENSION 12.90mm: PV083C(MALE)+SW096(FEMALE)
MATING DIMENSION 13.90mm: PV099C(MALE)+SV090C(FEMALE)
MATING DIMENSION 14.50mm: PV099C(MALE)+SW096(FEMALE)
MATING DIMENSION 15.45mm: PV068C(MALE)+SV136C(FEMALE)
MATING DIMENSION 16.85mm: PW082(MALE)+SV136C(FEMALE)
MATING DIMENSION 16.95mm: PV083C(MALE)+SV136C(FEMALE)
MATING DIMENSION 18.60mm: PV099C(MALE)+SV136C(FEMALE)
(3) RoHS

DOWNLOAD

	PART NUMBER	SIZE	FILE TYPE	DRAWINGS
	SMCXXXPV068C-R4H5-H	330KB	PDF	DOWNLOAD
	SMCXXXPV083C-R3H7-H	210KB	PDF	DOWNLOAD
	SMCXXXPV099C-R2H9-H	327KB	PDF	DOWNLOAD
	SMCXXXPW082-R7H5-H	132KB	PDF	DOWNLOAD
	SMCXXXSV062C-R7H2-H	321KB	PDF	DOWNLOAD
	SMCXXXSV090C-R3H7-H	206KB	PDF	DOWNLOAD
	SMCXXXSV136C-R2H5-H	202KB	PDF	DOWNLOAD
	SMCXXXSW096-R8H-H	125KB	PDF	DOWNLOAD
